| Rim | Size | PR | Li | SS | Overall Diameter (mm) | Section Width (mm) | Standard Rim | Tread Depth (mm) | Max. Load (KG) | Max. Load D (KG) | Pressure (kPa) | SW |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15 | 6.50R15LT | 10 | 106/101 | N | 730 | 185 | 5.50F | 10 | 950 | 825 | 560 | BSW |
| 7.00R15LT | 10 | 109/105 | N | 750 | 200 | 5.50F | 10 | 1030 | 925 | 560 | BSW | |
| 16 | 6.50R16LT | 10 | 107/102 | N | 750 | 185 | 5.50F | 10.5 | 975 | 850 | 560 | BSW |
| 7.00R16LT | 12 | 115/110 | N | 775 | 200 | 5.50F | 10.5 | 125 | 1060 | 670 | BSW |
| Handling | Handling |
|---|---|
| Wear Resistance | Wear Resistance |
| Cross-Country | Cross-Country |
| Braking | Braking |
